QNAP QXP-400eS-A1164


QNAP QXP-400eS-A1164

SKU: QXP-400eS-A1164 Category:


The QXP SATA expansion cards are designed for QNAP’s TL series JBOD storage enclosures that support SATA drives. Expand storage capacity easily by installing a QXP SATA expansion card into the PCIe slot of a QNAP NAS or Windows/ Ubuntu (Linux) PC, and then connect the TL series JBOD storage enclosures using an SFF-8088 (or SFF-8644) cable. The low-profile card form-factor allows QXP SATA expansion cards to be compatible with a wide variety of NAS, computers, and servers.

Controller Asmedia ASM1164
Connector 2 x SFF-8088
Supported SATA driver numbers 8 x SATA 6Gb/s drives (Each SFF-8088 connector supports four SATA drives)
PCIe interfaces PCIe Gen3 x4 (32Gbps)
Supported operating systems QTS 4.4.2 or later, QuTS hero
– Windows 8 or later
– Windows Server 2012 R2 or later
– Linux with Kernel 3.10 or later
Form factor Low-profile 119.65 x 68.9 x 17.24 mm (Without bracket 119.65 x 68.9 x 12 mm)
Cable QNAP provides 1.0M SFF-8088 cable for optional purchase. Order number: CAB-SAS10M-8088

Additional information

Weight 1 kg
Dimensions 25 × 15 × 5 cm
