Qnap TS-983XU-RP-8G NAS 9 Bay 8G DDR4 Intel Xeon E-2124 4-core 3.3 GHz processor Hot-swappable 2x10GbE 2xGbe RJ45 USB 3.2 1xPCle Slot 1U WOL

$5,265.00

Qnap TS-983XU-RP-8G NAS 9 Bay 8G DDR4 Intel Xeon E-2124 4-core 3.3 GHz processor Hot-swappable 2x10GbE 2xGbe RJ45 USB 3.2 1xPCle Slot 1U WOL

SKU: TS-983XU-RP-E2124-8G Category:

Description

Qnap TS-983XU-RP-8G NAS 9 Bay 8G DDR4 Intel Xeon E-2124 4-core 3.3 GHz processor Hot-swappable 2x10GbE 2xGbe RJ45 USB 3.2 1xPCle Slot 1U WOL

The Intel Xeon E based TS-983XU-RP enterprise NAS with up to 128 GB DDR4 ECC (Error Correcting Code) memory delivers server-grade performance with dependable reliability. It features Mellanox ConnectX-4 Lx 10GbE controllers that not only fulfill bandwidth-demanding applications but also support iSER to offload CPU workloads with boosted virtualization performance, while PCIe expansion allows for installing graphics cards to empower video surveillance, virtualization and AI applications. The performance-driven TS-983XU-RP provides you with advanced business-ready features, including software-defined SSD extra over-provisioning, software-defined networking & virtual switch, and much more

TS-983XU-RP-E2124-8G
CPU Intel Xeon E-2124 4-core 3.3 GHz processor (burst up to 4.3 GHz)
CPU Architecture 64-bit x86
Floating Point Unit
Encryption Engine (AES-NI)
System Memory 8 GB UDIMM DDR4 ECC (2 x 4GB)
Maximum Memory 128 GB (4 x 32 GB)
Memory Slot 4 x UDIMM DDR4
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 4 x 3.5-inch + 5 x 2.5-inch SATA 6Gb/s, 3Gb/s
Hot-swappable
SSD Cache Acceleration Support
Gigabit Ethernet Port (RJ45) 2
10 Gigabit Ethernet Port 2 x 10GbE SFP+ SmartNIC port
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot 1
Slot 1: PCIe Gen 3 x16
USB 3.2 Gen 1 port 4
USB 3.2 Gen 2 (10Gbps) Port 2 x Type-C USB 3.2 Gen 2 10Gbps
Form Factor 1U Rackmount
LED Indicators HDD 1-4, SSD 1-5, Status, LAN
Buttons Power, Reset
Dimensions (HxWxD) 43.3 ? 482.6 ? 507.54 mm
Weight (Net) 8.63 kg
Operating temperature 0 – 40 ?C (32?F – 104?F)
Power Supply Unit 300W(x2), 100-240V
Fan System fan: 3 x 40mm, 12VDC

Additional information

Weight 8.8 kg
Dimensions 6 × 49 × 51 cm
