Antec 300w TFX 80+ Gold PSU – OEM Bulk PSU for Small Form Factor Case – No Power cord > optional CBA-PWRCORD2

Description

Antec OEM by Seasonic 300W TFX PSU is TFX 12 V v.2.31 compliant and offers DC to DC converter design and important protection features for safe operations. It is perfect for desktop of mini ITX cases and with its 80 PLUS Gold rating it can achieve up to 90 % efficiency at 115 V AC at 50 % load. This unit supports the latest Intel and AMD platforms and with above 100,000 hours MTBF rate it is highly reliable.

Specifications
Input frequency 50 / 60 Hz
Inrush current at cold start 100 A max.
Efficiency 80 PLUS Gold
Line regulation ± 1 % (typical)
Load regulation ± 5 % (typical)
Cross regulation ± 5 % (typical)
Ripple / noise 1 %
MTBF, full load @ 25 °C ambient (excl. DC fan) > 100,000 hours
Active Power Factor Correction > 95 % (typical)

DC Outputs
+3.3 V +5 V +12 V (Combined) -12 V +5 Vsb Total continuous power Input Type
10 A 14 A 25 A 0.3 A 2 A 300 W 100240 VAC
70 W 300 W 3.6 W 10 W

TFX 12 V
80 PLUS Gold Certified
Safety: cUL, TUV, CB, CCC, BSMI
EMI / EMC: CE, FCC, RCM
Dimensions: 140 mm (L) x 85 mm (W) x 65 mm (H)

Optional Power Cord SKU: CBA-PWRCORD2
